5. Remove the reverse lamp switch M12×1.25
Caution: When install the reverse lamp switch M12×1.25, the
tightening torque is 26-36 N·m
6. Remove the gearbox
a.Use the wrench to remove the 5 M8×55 bolts, 1 M8×6 bolt and 2
M8×110 bolts
Caution: When install 5 M8×55 bolts, 1 M8×6 bolt and 2 M8×110
bolts. tightening torque is
b. Remove the gearbox assembly
7. Use the circlip pliers to remove the circlip for shaft
8. Remove the odometer drive gear
