d. Remove the 3rd-Gear driven gear assembly
Caution: When install the 3rd-Gear driven gear assembly, it should
use the plug gage to measure the 3rd-Gear driven gear assembly
axialclearance to ensure it is within 0.17-0.284mm
e. Remove the 3rd-Gear driven gear needle bearing
f. Use the special tools to press the second shaft to remove the inner
race of double inner-race ball bearing.
Remove the 1st-Gear driven gear
Caution: When install the 1st-Gear driven gear, it should use the
plug gage to measure the 1st-Gear driven gear axial clearance to
ensure it is within 0.17-0.284mm.
h. Remove the 1st-Gear driven gear needle bearing
