Transmission-33
10. Remove the high and low gear drive declutch shift shaft
11.Remove the second and fourth drive declutch shift shaft
12. Use the plastic hammer to knock out the rear output shaft
assembly, front output shaft assembly and chain out slightly
13. Remove the second/fourth shift block and high and low gear
shift fork
14. Remove the housing of transfer case
a. Use the wrench to remove 4 bolts M10
1.25 35 and 2 nuts
M10
1.25 connected the gearbox and tranafer case housing
Caution: The tightening torque is 30
42 N•m when install
the connecting bolt of gearbox and housing of transfer case
