Chapter 5 Front Panel Interface Front Panel Root Menu
© 2011 Harmonic Inc. 160 ProView 7000 v.2.4, Rev. A
5.2.2.4 Video Configuration Menu
The Video Configuration menu enables the user to set-up the decoded video stream
parameters for the modulated program. The Video configuration menu is dependant on the
video Codec (MPEG-2 or MPEG-4 AVC (H.264)) and format (SD or HD) of the video stream.
The video configuration menu provides access to sub-menus defined by the video format
selected (SD or HD).
To access the SD or HD Video Configuration screen:
❖ Navigate to Root > Decoding > Configuration > Video.
SD Format: Video Configuration Menu
HD Format: Video Configuration Menu
Codec and Format Sub-menu:
The Codec and Format Sub-menu provides access to the common video output parameters,
setting up the operation of the video stream modulation.
To access the Video General Sub-menu screen:
❖ Navigate
Root > 2 Decoding > 1 Configuration > Video > Codec and Format.
The screen provides access for setting-up the following parameters:
■ Decoding Codec – selects the video decoding mode. Options:
❑ Automatic
❑ MPEG-2
❑ H.264
■ Display Format – selects the video display format. Options:
❑ SD
❑ HD
❑ Automatic Resolution
Video
1 Codec and Format
2 Digital and Analog Outputs
Video
1 Codec and Format
2 Digital Output (SD/HD)
3 Composite Monitor Output (SD)
