Chapter 5 Front Panel Interface Front Panel Root Menu
© 2011 Harmonic Inc. 161 ProView 7000 v.2.4, Rev. A
NOTE: Changing the display format may take a few seconds. During this time the FP display freezes. The
Aspect Ratio Conversion feature is performed if the aspect ratio of the video in the incoming transport
stream is not the same as the configured aspect ratio for the output stream.
■ Buffer Mode – See 3.4 Low Delay Mode for details on Low Delay. Options:
❑ Normal
❑ Low Delay
Digital and Analog Outputs Sub-menu:
The Digital and Analog Outputs Sub-menu is provided when the video display format is set to
Standard Definition (SD).
To access the Video Digital and Analog Output Sub-menu screen:
❖ Navigate to Root > Decoding > Configuration > Video > Digital and Analog Outputs.
The screen provides access for setting-up the following parameters:
■ Video Format – selects the video format.
Options: NTSC, PAL-B/G, -I, -D, -M, -N, French SECAM.
■ Aspect Ratio Conversion – selects the aspect ratio conversion for the output stream.
Options (related to selected aspect ratio):
❑ 4:3 Aspect ratio
•Center-cut
• Letterbox
• Full Screen
❑ 16:9 Aspect ratio
•Center-cut
• Pillarbox (Side-bars)
• Full Screen
•AFD
■ Aspect ratio – selects the aspect ratio.
Options:
•4:3
• 16:9
Digital Output Sub-menu:
The Digital Output Sub-menu is provided when the video display format is set to High
Definition (HD).
To access the Video Digital Output Sub-menu screen:
❖ Navigate to Root > Decoding > Configuration > Video > Digital Output.
