100
_____________________________________________________________________________________________
6.6 PASS or FAIL Determination
______________________________________________________________________________________________
6.6.1 "PASS" State
WARNING
Even when a test has been terminated, there may still be voltage in the
output-voltage terminal. Before touching the output-voltage terminal,
H.V. TEST LEAD, or tested object, make sure that no high voltage is
being applied to the output, confirm the following items.
(1) The analog voltmeter reads 0 kV.
(2) The
DANGER
lamp is OFF.
(3) The
READY
lamp is lit (it is off in the Double Action mode).
6.6 PASS or FAIL Determination
・
When all set test conditions have been met, the unit switches to the PASS
state. As soon as the unit switches to this state, it stops outputting voltage.
・
When the test is forcibly terminated by pressing the
STOP
key, no
screening is performed.
・
During the insulation-resistance test, if the output voltage doesn't reach a
level between 5% lower and 50% higher than the set test voltage value,
screening will not be performed.
Optional Functions
The PASS state is held using the PASS Hold function. (See Section 7.1)
During the hold state, the result of the terminated test can be displayed
using the / keys.
Flow of PASS determination
1. Press the
START
key to start a test.
2. The test set by the program file is conducted in each step.
3. When all test conditions have been met, the unit switches to the PASS
state. In this state, PASS lights up.
To Next Page
