11.1 Basic Specifications
______________________________________________________________________________________________
11.1.6 Other Functions
Memory function This function allows test conditions to be saved.
Withstand-voltage mode: test type (AC50 Hz/AC60 Hz/DC), test voltage, current
determination for upper- and lower-limit values, test time, ramp-up/down time.
Insulation-resistance mode: test voltage, resistance determination for upper- and
lower-limit vales, test time, and delay time
Up to 10 test conditions can be saved or loaded for both voltage and insulation-
resistance mode.
Pass hold function Enable this function to hold the Pass state when detected, to facilitate
confirmation.
Fail hold function Enable this function to hold the Fail state when detected, to facilitate
confirmation.
Hold function Retains the measured value when the test is forcibly terminated.
Buzzer settings Buzzer volume settings for test screening and errors (buzzer volume settings are
to be performed for PASS and FAIL separately)
Momentary output This function allows current output only when the START key is pressed. The
START key on the remote control or the START signal via external I/O has the
same effect.
Double action Enable this function to allow testing to start only when the START key is pressed
within about 0.5 seconds after the STOP key.
Fail mode Enable this function to restrict hold release to the STOP key on the main unit.
PC command "START" This function validates or invalidates START from a PC interface.
Interlock function To set ON/OFF for the interlock function
Ramp-up screening To set ON/OFF for screening during the ramp-up time (Withstand-voltage test)
Insulation-resistance
range
Fixed range/ auto range (However, no determination is made when Auto Range
is selected.)
TEST-signal output To set ON/OFF for external I/O and TEST-signal output when TEST is flashing
Test end mode Enable this mode to terminate an insulation-resistance test when the set time of
the timer has elapsed (unrelated to screening), or to terminate the test at PASS
or FAIL screening (only when the timer is set). (Insulation-resistance test)
Maximum output voltage To set the upper-limit for the output voltage (common to withstand-voltage mode
and insulation-resistance mode)
PC interface To select an interface from among RS-232C (9,600 bps), RS-232C (19,200 bps),
and GP-IB. When GP-IB is selected, address (0 to 30) is to be set.
