8.1 Saving Preset Values
______________________________________________________________________________________________
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Withstand-voltage
mode
Test type (AC50 Hz, AC60 Hz, DC), Test-voltage value,
Upper-limit value, Lower-limit value, Test time, Ramp-
up time, Ramp-down time
Insulation-resistance
mode
Test-voltage value, Upper-limit value, Lower-limit value,
Test time, Delay time
NOTE
Optional function settings cannot be saved.
8.1.1 Procedure for Saving Data
Chapter 8
Saving/loading Preset Values
8.1 Saving Preset Values
The following describes a function used to save values set in the READY
state (withstand-voltage mode or insulation-resistance mode). Up to twenty
parameters may be saved.
Up to 10 parameters may be saved in the each mode, such as the withstand-
voltage and insulation-resistance modes. To retrieve saved data, follow the
procedures described in Section 8.2.
The following parameters can be saved:
You must make the settings first before they can be saved. Parameters
cannot be changed on the Save screen.
(1) Selecting a test mode
Select the test mode where you want to save settings for the
W
or
I
key.
(2) Displaying the save screen
With the target preset value displayed in the READY state, press
SHIFT
+
keys to shift to the save screen.
In the "save screen", the saved data for the file number replaces the target
value displayed in the READY state. The first saved data displayed is the
last data from the previous "save screen".
