10.5 GP-IB Interface
______________________________________________________________________________________________
10.5.1 Specifications
10.5.2 Preparing for Data Transfer
10.5 GP-IB Interface
(1) Command system
The GP-IB command system of this unit conforms to IEEE-488.2 (1987).
(2) Connector
This is a 24-pin connector for the IEEE488 bus. Standard bus cables can be
used together.
(1) Connecting cable
Connect the GP-IB connector of this unit to the GP-IB connector of the
controller using a GP-IB CONNECTOR CABLE. Use either of the following
HIOKI genuine products:
9151-02 GP-IB CABLE (2 m)
(2) Connection to Computer
1
. Connect the 3153 to the computer using the GP-IB cable.
2
. After connecting, turn on both 3153 and personal computer power.
