4.5 "PASS" or "FAIL" Determination
______________________________________________________________________________________________
4.5.1 "PASS" State
WARNING
Even when a test has been terminated, there may still be voltage in the
output-voltage terminal. Before touching the output-voltage terminal,
H.V. TEST LEAD, or tested object, make sure that no high voltage is
being applied to the output, confirm the following items.
(1) The analog voltmeter reads 0 kV.
(2) The
DANGER
lamp is OFF.
(3) The
READY
lamp is lit (it is off in the Double Action mode).
4.5 "PASS" or "FAIL" Determination
When the set time has elapsed, if the measured resistance value
≧
lower -
limit value or
≦
upper-limit value, the unit will change to the PASS state.
As soon as the unit switches to the PASS state, it stops outputting voltage.
If the test time has not been set, PASS screening is not performed. To the
test, press the
STOP
key, which will forcibly terminate the test.
If the output voltage doesn't reach a level between 5% lower and 50%
higher than the set test voltage value, screening will not be performed.
Optional Functions
The PASS state is held using the PASS Hold function. (See Section 7.1)
If the test time is set, the test can be forcibly terminated when the
measured resistance value enters the PASS range before the preset time
has elapsed. This is convenient when testing objects that contains capacity
loads. (See Section 7.11)
