Hioki 3153 - Program Function

224
_____________________________________________________________________________________________
11.1 Basic Specifications
______________________________________________________________________________________________
RS-232C
Transmission mode Start-stop synchronization, full duplex
Transfer rate 9600 bps/ 19200 bps
Data length 8 bit
Parity None
Stop bit 1 bit
Hand shake No X flow, hardware flow control
Delimiter CR, CR + LF for reception
CR + LF for transmission
GP-IB The GP-IB command system of this unit conforms to IEEE-488.2 (1987).
11.1.5 Program Function
Number of the files 32 files (max.)
Number of the steps 50 steps (max.) / file
Setting items Setting items for each step
Types of tests: AC withstand-voltage test/DC withstand-voltage test/insulation-
resistance test
Test point: Scanner No. (each HIGH/LOW scanner No., or High-side No. against
COM)/scanner control OFF
Test settings: Condition settings for withstand-voltage and insulation-resistance
tests
PC Interface (Either RS-232C or GP-IB can be enabled.)
Connection of scanners
Up to 4 scanners can be connected.
START key priority order
RS-232C interface or GP-IB > REMOTE CONTROL BOX > External I/O >
START
key on this units panel (However, this is when START is enabled
using the RS-232C interface or GP-IB.)
