8.2 Loading Preset Values
______________________________________________________________________________________________
Withstand-voltage
mode
Test type (AC50 Hz, AC60 Hz, DC), Test-voltage value,
Upper-limit value, Lower-limit value, Test time, Ramp-
up time, Ramp-down time
Insulation-resistance
mode
Test-voltage value, Upper-limit value, Lower-limit value,
Test time, Delay time
8.2.1 Procedure for Loading Data
8.2 Loading Preset Values
The following describes how to load saved data.
Up to 10 data items may be saved in the each mode, such as the voltage and
insulation-resistance modes. Use this function to instantly change a preset
value.
The following parameters can be saved:
(1) Selecting a test mode
Select the test mode where you want to save settings for the
W
or
I
key.
(2) Displaying the load screen
Press
SHIFT
+ keys in the READY state to shift to the load screen.
In the load screen, a number for saved data equal to the file preset replaces
the target value displayed in the READY state.
The first saved data displayed is the last data from the previous load screen.
