7.7 Interface Command "START"
______________________________________________________________________________________________
0:
Not set (Initial setting)
1:
Set
NOTE
Unless the control program on your PC is complete, select "
0
: Not set."
7.7 Interface Command "START"
When RS-232C is used for control, settings can be made to specify whether
to accept the test start command ":STAR."
If "
0
: Not set" is selected, this command is disregarded.
If "
1
: Set" is selected, a test is started when the ":STARt" command is
received.
1. Press
SHIFT
+
STOP
keys while in READY state to display the Optional
function setting screen.
2. Use the
/
keys to move the flashing cursor to the position shown in the
figure.
3. Use the
/
keys to set a value at the flashing cursor location.
4. To complete the optional settings, press
SHIFT
+
STOP
keys. The unit
reverts to the READY state.
