Hioki 3153 - Power Cord Connection

11
_____________________________________________________________________________________________
2.4 Power Cord Connection
______________________________________________________________________________________________
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
WARNING
Before turning the product on, make sure the source voltage matches
that indicated on the product's power connector. Connection to an
improper supply voltage may damage the product and present an
electrical hazard.
To avoid electrical accidents and to maintain the safety specifications
of this instrument, connect the power cord provided only to a 3-
contact (two-conductor + ground) outlet.
Supply voltage indicated on the rear panel
2
3
2.4 Power Cord Connection
1. Be sure that the main power switch is turned to OFF.
2. Connect the grounded three-core power cord provided to the power inlet
on the back of the unit.
3. Insert the plug into the grounded outlet.
