Hioki 3153 - Buzzer

154
_____________________________________________________________________________________________
9.2 Buzzer
______________________________________________________________________________________________
NOTE
If an excessive force is placed on the volume adjustment knob, it may be
fractured.
The buzzer that sounds in the event of an error caused by improper key
o
p
erations is at the same volume as the buzzer that sounds for FAIL screenin
g
.
9.2 Buzzer
A buzzer sounds during PASS or FAIL screening and in the event of an error
due to improper key operations. Two buzzer volume adjustment knobs are
provided on the rear panel: one for PASS screening and one for FAIL
screening. Volume adjustments can be made using the knobs.
1. Check the analog voltmeter and the
DANGER
lamp to make sure a voltage
is not being output.
2. Using a screwdriver, adjust the volume adjustment knob. To increase the
volume, turn the knob clockwise. To decrease it, turn it counterclockwise.
