11.1 Basic Specifications
______________________________________________________________________________________________
Voltage 0.20 - 5.00 kVDC
Voltage testing method PWM switching
Output capacity 50 VA (continuous)
Setting method Digital setting (Setting resolution: 0.01 kV)
Accuracy (1.5% of the setting value+2 dgt.)
Fluctuation rate 16% or less (Maximum rating: 5 kV/10 mA
No load: Resistance load)*
Ripple voltage 6% of output voltage max. (5 kV DC output, 10 mA Resistance load)
Current 10 mA (continuous)
Voltage measurement Average value display
Digital: 0.00 - 5.00 kV DC (full-scale)
Accuracy
1.5%f.s.
Analog: 0 - 5.0 kV DC (full-scale)
Accuracy
5%f.s.
Current measurement
range
0.01 to100.0 mA (AC), 0.01 to 10.0 mA (DC)
Designated value AC: Average value rectified effective value display (digital)
DC: Average value display (digital)
Measurement range 10 mA range (AC/DC), 100 mA range (AC)
Measured area and
resolution
0.00 to 10.00 mA/ 0.01 mA (10 mA range)
10.1 to 100.0 mA/ 0.1 mA (100 mA range)
Accuracy (2% rdg.+5dgt.) for all ranges *
Decision method Window comparator method ( digital setting )
Decision contents UPPER-FAIL : when measured current exceeds the upper-limit setting
PASS : when measured current remains between the upper- / lower-
limit settings for set time
LOWER-FAIL : when the measured current is below the lower-limit setting
Decision process Output to the display, beeper sound, signals to EXT I/O for each decision result
Setting range AC: 0.1 to 100 mA (Upper-limit value), 0.1 to 99 mA (Lower-limit value)
DC: 0.1 to 10 mA (Upper-limit value), 0.1 to 9.9 mA (Lower-limit value)
Setting resolution 0.1 mA (0.1 to 9.9 mA)/ 1 mA (10 to 100 mA)
DC Test Voltage
*: No load
When loaded with 40 MΩ (input impedance during measurement)
Current Detection (AC/DC common)
* The error limit is added when the scanner is used.
* For DC measurements, if the capacitance that is connected in parallel with
the load is over 0.01 μF, the table above will not apply.
Decision Function
