APPENDIX 2
_____________________________________________________________________________________________
Appendix 2 9614 REMOTE CONTROL BOX (DUAL)
______________________________________________________________________________________________
Ambient operating
conditions
0to40 (32 to 104 ), 80% RH or less (no
condensation)
Ambient storage
conditions
-10 to 50 (14 to 122 ), 90% RH or less (no
condensation)
Operating place Indoors, max. 2000 m (6562 feet) height
Dimensions Approx. 270W x 50H x 30D mm
(10.63"W x1.97"H x 1.18"D)
(excluding projections)
Mass Approx. 700 g (24.7 oz.)
Cord length Approx. 1500 mm (59.06")
Appendix 2 9614 REMOTE CONTROL BOX (DUAL)
Unlike the 9613, the 9614 REMOTE CONTROL BOX (DUAL) has two
START
keys. Pressing both keys is equivalent to pressing the
START
key on
the unit. By using the Momentary-OUT function in Optional Functions, the
9614 allows the REMOTE CONTROL BOX to be used with both hands,
thus ensuring safer testing.
