55
_____________________________________________________________________________________________
4.3 "SETTING" State
______________________________________________________________________________________________
(3) Setting an lower-limit value
Press the key to move the flashing cursor to the lower-limit value.
In this example, switch from
10.0 MΩ
to
100 MΩ
using the / keys.
To change the lower-limit value, press / keys.
Press the keys,
SHIFT
+
/
key. The value increases or decreases 10 times
more rapidly than when the
SHIFT
key is not held down.
(4) Setting a upper-limit value
Using the key, move the flashing cursor to the upper-limit value.
The upper-limit value is set at
2000 MΩ
. Turn it
OFF
, as it is not needed. To
change to
OFF
, press the
ON/OFF
key.
