Honeywell UDC2800 User Manual

122
Function
Prompt
Selections or
Range of
Setting
Parameter Definition
TC M High M Thermocouple High (Ni-Ni-Moly)
TC M Low M Thermocouple Low (Ni-Ni-Moly)
TC N High N Thermocouple High (Nicrosil-Nisil)
TC N Low N Thermocouple Low (Nicrosil-Nisil)
TC R R Thermocouple
TC S S Thermocouple
TC T High T Thermocouple High
TC T Low T Thermocouple Low
TC W High W5W26 Thermocouple High
TC W Low W5W26 Thermocouple Low
TC PR40-
PR20
PR40-PR20 Thermocouple
RTD Pt100 100 Ohm RTD High
RTD Pt100
Low
100 Ohm RTD Low
RTD Pt200 200 Ohm RTD
RTD Pt500 500 Ohm RTD
0-20mA 0 to 20 Milliamperes
4-20mA 4 to 20 Milliamperes
0-10mV 0 to 10 Millivolts
0-50mV 0 to 50 Millivolts
0-100mV 0 to 100 Millivolts
0-5 V 0 to 5 Volts
1-5 V 1 to 5 Volts
0-10 V 0 to 10 Volts
Chapter 4 - Configuration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
