Honeywell UDC2800 User Manual

Function
Prompt
Selections or
Range of
Setting
Parameter Definition
Input 2 Type TC Differential Thermocouple Differential
Slidewire 100-1K ohm Slidewire (For Position Proportional
Applications)
Input 2
Transmitter
TC B
TC E High
TC E Low
TC J High
TC J Mid
TC J Low
TC K High
TC K Mid
TC K Low
TC M High
TC M Low
TC N High
TC N Low
TC R
TC S
TC T High
TC T Low
TC W High
TC W Low
TC PR40-
PR20
RTD Pt100
Transmitter Characterization —This selection lets you
instruct the controller to characterize a linear input
to represent a non-linear one. If characterization is
performed by the transmitter itself, then select
Linear.
ATTENTION: Prompt only appears when a
linear actuation is selected at prompt Input 2
Type.
FOR EXAMPLE:
If input 2 is a 4 to 20 mA signal, but the signal
represents a type K H thermocouple, then configure
K TC H and the controller will characterize the 4 to
20 mA signal so that it is treated as a type K
thermocouple input (high range).
Parameter definitions are the same as in Input 2
Type.
123
Chapter 4 - Configuration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
