140
Function Prompt
Selections or Range
of Setting
Parameter Definition
SP Setpoint represents the value of the
setpoint currently in use (LSP1,
LSP2, LSP3, LSP4, RSP or CSP) and
is shown in the same units as those
used by the PV.
Local SP 1 Auxiliary output represents Local
Setpoint 1 regardless of active
setpoint.
Local SP 2 Auxiliary output represents Local
Setpoint 2 regardless of active
setpoint.
Local SP 3 Auxiliary output represents Local
Setpoint 3 regardless of active
setpoint.
Local SP 4 Auxiliary output represents Local
Setpoint 4 regardless of active
setpoint.
Remote SP Remote Setpoint represents the
configured RSP regardless of the
active SetPoint.
Input Algorithm 1 Input Algorithm 1 Output represents
the output from input algorithm 1.
CO Range 4-20mA
0-20mA
Auxiliary Current Output Range —
Allows the user to easily select 4-
20mA output or 0-20mA output
operation without the need for
recalibration of the instrument.
ATTENTION: Changing the
Auxiliary Current Output
Range will result in the loss of
Field Calibration values and
will restore Factory Calibration
values.
CO Low Value Low Scale Value Auxiliary Output Low Scaling Factor
Chapter 4 - Configuration
