Function
Prompt
Selections or Range
of Setting
Parameter Definition
prompt A1S1 Type to actuate. The value
depends on what the setpoint has been
configured to represent. No setpoint is
required for alarms configured for
Communications SHED.
ATTENTION: For SP Programming the
value is displayed as PxSy for which
the event applies. PxSy = Program x,
Segment y.
ATTENTION: In Easyset app, the SP
Programming value is displayed as
Px.Sy00, for which the event applies.
Px.Sy00 = Program x. Segment y 00.
For example, Program2. Segment300
(2.300).
This prompt does not appear for “Alarm on
Manual” type alarm. For example: A1S1 Type
= Manual.
A1S1 State If Setpoint Programming is disabled or if the
Alarm Type is not configured for Event
On/Off:
Alarm 1 Setpoint 1 State —Select whether
you want the alarm type chosen in prompt
A1S1 Type to alarm High or Low.
High Alarm High Alarm
Low Alarm Low Alarm
A1S1 Event If Setpoint Programming is enabled and if
the Alarm Type is configured for Event
On/Off:
Alarm 1 Segment Event 1 —Select whether
you want the alarm type chosen in prompt
A1S1 Type to alarm the beginning or end of a
segment in setpoint Ramp/Soak
programming.
155
Chapter 4 - Configuration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
