Honeywell UDC2800 User Manual

206
Step Operation Press Result
If "PB" is selected under the Control set up
group function prompt "Gain" or
"Proportional Band", then set the
Proportional Band 2 to:
Function key Configure the Gain 2 value.
20 Select Rate 2
Min Value
Increment key
or Decrement
key
Until you see Rate 2 Min.
Function key Enter in the first configuration prompt of
Rate 2 Min.
Increment key
or Decrement
key
Configure Rate 2 Min value as 0.00.
Press the Function key again to configure
the value.
21 Select Options
set up group
Setup key Until you see Options set up group.
22 Select a Digital
Input
Function key Enter in the first function prompt of the
Options set up group.
Increment key
or Decrement
key
Until you see DI 1 Function or DI 2 Function.
This selection determines which Digital
Input will be used for Auto/Manual Station
operation.
23 Select
Auto/Manual
Station function
Function key Enter in the first configuration prompt of DI
1 Function or DI 2 Function.
Increment key
or Decrement
key
Until you see To Auto/Man Station.
Function key Select the selection To Auto/Man Station.
DO NOT SELECT:
Chapter 5 - Monitoring and Operating the Controller

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
