Honeywell UDC2800 User Manual

222
Program record sheet
Draw your ramp/soak profile on the record sheet shown in table
below and fill in the associated information in the blocks provided.
This will give you a permanent record of your program and will assist
you when entering the Setpoint data.
Table 5-24: Program record sheet
Prompt Function Segment Value
Start Segment Start Seg.
End Segment End Seg.
Ramp Unit Engr. Unit for Ramp
Recycles Number of Recycles
Soak Deviation Deviation Value
Program Termination Controller Status
Program End State Controller
State at end
Key Reset/Rerun Reset SP Program
Hot Start PV Hot Start
Program Initialization or power up in SPP
Segment 1 Ramp Ramp Time 1
Segment 2 SP Soak SP 2
Segment 2 Time Soak Time 2
Segment 3 Ramp Ramp Time 3
Segment 4 SP Soak SP 4
Segment 4 Time Soak Time 4
Segment 5 Ramp Ramp Time 5
Segment 6 SP Soak SP 6
Segment 6 Time Soak Time 6
Segment 7 Ramp Ramp Time 7
Chapter 5 - Monitoring and Operating the Controller

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
