Honeywell UDC2800 User Manual

296
If an analog configuration is highlighted with red text or a digital
configuration is shown blank, it means that the value read up
from the instrument is now out of range, either because of
previous changes to the instrument’s configuration or because of
incompatibilities with a downloaded configuration set. Change
the configuration to an in-range setting to correct the error.
ATTENTION: In Easyset app, the SP Programming value is
displayed as Px.Sy00, for which the event applies. Px.Sy00 =
Program x. Segment y 00. For example, Program2.
Segment300 (2.300).
5. Once the configuration is completed, click Save. The Success
dialog appears. Click OK.
Chapter 10 - Configuration via Honeywell EasySet

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
