Honeywell UDC2800 User Manual

7
Background Tests and Diagnostic 258
Controller Failure Symptoms 263
Troubleshooting Procedures 264
Procedure #1 265
Procedure #2 265
Procedure #3 266
Procedure #4 267
Procedure #5 268
Procedure #6 269
Procedure #7 271
Procedure #8 271
Procedure #9 272
Procedure #10 273
Restoring Factory Configuration 274
Chapter 9 - Parts List 276
Exploded View 276
Removing the chassis 281
Chapter 10 - Configuration via Honeywell EasySet 282
Communications Setup 283
Upload 288
Offline Configuration 290
Download 293
Online Configuration 294
Maintenance Data 298
About EasySet 301
Firmware update through Easyset App 302
Transfer configuration from the legacy device to the UDC2800 306
Contents

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
