Honeywell UDC2800 User Manual

Function
Prompt
Selections or
Range of
Setting
Parameter Definition
Run/Hold
Key
Allows you to disable the Run/Hold key, for either SP
Ramp or SP Program. The Run/Hold key is never
disabled when used to acknowledge a latched alarm
1.
Disable Disable the Run/Hold Key
Enable Enable the Run/Hold Key
ATTENTION: Can only be viewed if Lockout is
configured for None.
Reset Reset the latched alarm using the Run/Hold key
combination after the alarm condition is complete.
SP Select
Key
Setpoint Select Key Lockout allows you to disable the
Setpoint Select function
Disable Disable the Setpoint Select function
Enable Enable the Setpoint Select function
ATTENTION: Can only be viewed if Lockout is
configured for None.
Restore
Settings
Allows you to reset the controller
Disable Disable
Enable Enable
Restore*
It allows you to reset the controller to factory settings
while preserving configuration.
ATTENTION: The device will restart if enabled.
Disable Disable
Enable Enable
Change
Password
0 to 9999 Allows you to change the password.
NOTE: The password is for keyboard entry only
75
Chapter 4 - Configuration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
