Honeywell UDC2800 User Manual

80
Function
Prompt
Selections or
Range of
Setting
Parameter Definition
1. Control Algorithm of the Algorithms set up group is
configured as PID A, PID B, PD+Manual Reset or Three
Position Step.
2. PID Sets of the Control set up group is configured as
4 Sets Keyboard, 4 Sets PV Swithcover or 4 Sets SP
Switchover.
3. Proportion Unit of the Control set up group is
configured as Proportional Band or Gain.
Rate 4 Min 0.00 to
10.00
minutes
This is the same as above except that it applies to
Duplex models for the "COOL" zone of Heat/Cool
applications or for the second set of PID constants.
Reset
Mins/Rpt 4
Reset
Rpts/Min 4
0.02 to
50.00
These are the same as above except that they apply to
Duplex models for the "COOL" zone of Heat/Cool
applications or for the second set of PID constants.
Cycle Time 1
Sec
1 to 120
seconds
Cycle Time 1 (Heat) determines the length of one time
proportional output relay cycle. Defined as "HEAT" cycle
time for Heat/Cool applications.
NOTE: It only appears when Output Algorithms is
configured as Time Simplex, Time Duplex or
Current Time in the Output set up group.
Cycle Time 1 Sec —Electromechanical relays
Cycle Time 2
Sec
1 to 120
seconds
Cycle Time 2 (COOL) is the same as above except it
applies to Duplex models as the cycle time in the
"COOL" zone of Heat/Cool applications or for the
second set of PID constants.
NOTE: It only appears when Output Algorithms is
configured as Time Duplex or Time Current in the
Output set up group.
Cycle Time 2 Sec —Electromechanical relays
Chapter 4 - Configuration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
