A 17 Motherboard Assembly
lb
remove the
Al7
motherboard assembly along with the card cage, continue
with the following step:
13. Referring to the
figure
on the following page, remove the front frame (item
1) and rear frame (item 6) by removing the attaching screws (item 7). At
this point, only the motherboard/card cage assembly should remain. This
whole assembly is replaceable.
1442
Assembly Replacement and Post-Repair Procedures
