Absolute Maximum Ratings Thermal Information
Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .+8.0V
Input, Output or I/O Voltage . . . . . . . . . . . . GND-0.5V to V
CC
+0.5V
ESD Classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Class I
Operating Conditions
Operating Voltage Range . . . . . . . . . . . . . . . . . . . . . +4.5V to +5.5V
Operating Temperature Range. . . . . . . . . . . . . . . . -55
o
C to +125
o
C
Input Low Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0V to +0.8V
Thermal Resistance (Typical) θ
JA
(
o
C/W) θ
JC
(
o
C/W)
CERDIP Package . . . . . . . . . . . . . . . . 55 12
CLCC Package . . . . . . . . . . . . . . . . . . 65 14
PDIP Package . . . . . . . . . . . . . . . . . . . 55 N/A
PLCC Package . . . . . . . . . . . . . . . . . . 65 N/A
SOIC Package. . . . . . . . . . . . . . . . . . . 75 N/A
Storage Temperature Range. . . . . . . . . . . . . . . . . .-65
o
C to +150
o
C
Maximum Junction Temperature Ceramic Package . . . . . . . +175
o
C
Maximum Junction Temperature Plastic Package. . . . . . . . . +150
o
C
Maximum Lead Temperature Package (Soldering 10s) . . . . +300
o
C
(PLCC and SOIC - Lead Tips Only)
Die Characteristics
Gate Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1250 Gates
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation
of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
DC Electrical Specifications V
CC
= +5.0V ±10%, T
A
= 0
o
C to +70
o
C (C82C59A), T
A
= -40
o
C to +85
o
C (I82C59A), T
A
= -55
o
C to
+125
o
C (M82C59A)
SYMBOL PARAMETER MIN MAX UNITS TEST CONDITIONS
V
lH
Logical One Input Voltage 2.0
2.2
-V
V
C82C59A, I82C59A
M82C59A
V
IL
Logical Zero Input Voltage - 0.8 V
V
OH
Output HIGH Voltage 3.0
VCC -0.4
-V
V
I
OH
= -2.5mA
l
OH
= -100µA
V
OL
Output LOW Voltage - 0.4 V l
OL
= +2.5mA
II Input Leakage Current -1.0 +1.0 µAV
IN
= GND or V
CC
, Pins 1-3, 26-27
IO Output Leakage Current -10.0 +10.0 µAV
OUT
= GND or V
CC
, Pins 4-13, 15-16
ILIR IR Input Load Current -
-
-200
10
µA
µA
V
IN
= 0V
V
IN
= V
CC
lCCSB Standby Power Supply Current - 10 µAV
CC
= 5.5V, V
IN
= V
CC
or GND Outputs
Open, (Note 1)
ICCOP Operating Power Supply Current - 1 mA/MHz V
CC
= 5.0V, V
IN
= V
CC
or GND, Outputs Open,
T
A
= 25
o
C, (Note 2)
NOTES:
1. Except for IR0 - lR7 where V
IN
= V
CC
or open.
2. ICCOP = 1mA/MHz of peripheral read/write cycle time. (ex: 1.0µs I/O read/write cycle time = 1mA).
Capacitance T
A
= +25
o
C
SYMBOL PARAMETER TYP UNITS TEST CONDITIONS
CIN Input Capacitance 15 pF FREQ = 1MHz, all measurements reference to
device GND.
COUT Output Capacitance 15 pF
CI/O I/O Capacitance 15 pF
82C59A
