514
Keysig
ht N9038A MXE Service Guide
Replaceable Parts
Har
dware
Figure 17-18
Cable Hold Downs
Item
Description
Part Number
1
MP57
Cable Hold Down 1 (158 mm)
5023-1397
2
MP58
Cable Hold Down 2 (48 mm)
5023-1379
3S
c
r
e
w
M3 X0.5 (8 mm)
0515-0372
494
496
