Kodiak 100 Series - Page 270

Pilot’s Operating Handbook
7-30
DO NOT USE FOR FLIGHT OPERATIONS
Section 7
AIRPLANE & SYSTEMS DESCRIPTIONS
100 SERIES
Systems
Wind Data
Wind direction and speed in knots can be displayed relative to the aircraft in a
window to the upper left of the HSI. When the window is selected for display,
but wind information is invalid or unavailable, the window displays NO WIND
DATA. Wind data can be displayed in three different ways.
Figure 7-26 – Wind Data
No Data
Option 2
Option 1
Option 3
