Kodiak 100 Series User Manual

Pilot’s Operating Handbook
7-145
DO NOT USE FOR FLIGHT OPERATIONS
Section 7
AIRPLANE & SYSTEMS DESCRIPTIONS
100 SERIES
Systems
Trafc Status Banner
Annunciation
Description
TA OFF SCALE
A Trafc Advisory is outside the selected display range.*
Annunciation is removed when trafc comes within the selected
display range.
TA X.X ± XX ↕
System cannot determine bearing of Trafc Advisory.**
Annunciation indicates distance in nm, altitude separation in
hundreds of feet, and altitude trend arrow (climbing/descending).
AGE MM:SS
Appears if trafc data is not refreshed within 6 seconds.
If after another 6 seconds data is not received, trafc is removed
from the display.
The quality of displayed trafc information is reduced as the age
increases.
TRFC COAST
The displayed data is not current (6 to 12 seconds since last
message).
The quality of displayed trafc information is reduced when this
message is displayed.
TRFC RMVD
Trafc is removed because it is too old for coasting (12 to 60
seconds since last message).
Trafc may exist within the selected display range, but it is not
displayed.
TRFC FAIL
Trafc data has failed.
NO TRFC DATA
Trafc has not been detected.
TRFC UNAVAIL
The trafc service is unavailable or out of range.
*Shown as a symbol on Trafc Map Page
**Shown in center of Trafc Map Page
Figure 7-99 – TIS Trafc Status Annunciations
Comparator Annunciations
Comparator Window Text Condition
ALT MISCOMP
Difference in altitude sensors is > 200 ft.
IAS MISCOMP
If both airspeed sensors detect < 35 knots, this is inhibited.
If either airspeed sensor detects > 35 knots, and the
difference in sensors is > 10 knots.
If either airspeed sensor detects > 80 knots, and the
difference in sensors is > 7 knots.
HDG MISCOMP
Difference in heading sensors is > 6 degrees.
PIT MISCOMP
Difference in pitch sensors is > 5 degrees.
ROL MISCOMP
Difference in roll sensors is > 6 degrees.
ALT NO COMP
No data from one or both altitude sensors.
IAS NO COMP
No data from one or both airspeed sensors.
HDG NO COMP
No data from one or both heading sensors.
PIT NO COMP
No data from one or both pitch sensors.
ROL NO COMP
No data from one or both roll sensors.
Figure 7-100 – Comparator Annunciations
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
