Read First
About notational convention of the system
Options, such as screen names / button names / on-screen choices, are surrounded by [ ].
Buttons are composed of the push buttons on the mini console and those selective buttons to be touched for the
desired operation on the LCD monitor screen. However, button assignments are mentioned based on the default set-
tings.
For a push button on the mini console → XX button
For an on-screen button → [
] button
Example)
FREEZE
→ FREEZE button
About operating procedure
Operations are numbered in order of operational order for illustrative purposes.
The description of the procedures does not always start on the top study screen.
">" is used to show which button or option on the top screen a user should select to switch to the target screen.
Example)
For an operating procedure to be started by pressing the [
] button in the menu section on the [ ] screen and by
pressing [
] button
[
] screen > [ ] button > [ ] button
How to view the screens / images plotted in this document
The gures and images listed in this document are developed as a form of sample image, non-ultrasound gure or
image, or illustration. Settings, such as a screen menu layout and the number of on-screen buttons, vary depending
on the presets of the system, and the extraction conditions of an ultrasound image dier according to the transducer
and mode used or the observed area. Use the plotted gures and images as a guide to understand the procedures.
