Konica Minolta SONIMAGE HS2 - 4.6.3 Trace Mode

4.6 Multi-image Mode
167
Chapter 4
4.6.3 Trace Mode
Displays a B image (including color images) and trace data indicated by the cursor on the B image.
Trace mode is available on a layout in M-, PW / CW Doppler-, or PW-TDI-mode.
Press either one of the mode buttons to display trace mode and, as necessary, press any of the following buttons.
z
Simul. mode
In M-, PW Doppler-, or PW-TDI-mode, both B- and trace images are put in a live state.
1
Changes to either M-mode, PW Doppler-mode, or PW-TDI-mode.
2
Press .
• Both B-images and trace images are displayed in a live state.
z
Update mode
In M-, PW / CW Doppler-, or PW-TDI-mode, either of B- or trace images is put in a live state and the other image is
put in a frozen state.
M-mode is only updatable during Mc.
1
Changes to either M-mode, PW / CW Doppler-mode, or PW-TDI-mode.
2
Press to switch between live and frozen states.
• Switches between live / frozen states each time you press .
z
Full trace mode
Enlarges trace mode-data to full screen.
1
Changes to either M-mode or PW / CW Doppler-mode.
2
Press .
• Displays real-time trace data in full screen.
• Press
again to return to the normal display.
• The
is used to switch the trace display to full screen.
