1.6 System Conguration and Part Name
1.6.2 Part Name
z
Front (when used)
LCD monitor
Touch panel-type LCD
Handle
• You can hold the handle for carrying the system.
Air vent
Transducer connector
(without a transducer mounted)
Mini console
Transducer connector lock
z
Rear (when used)
Side panel
(Right side)
Side panel
(Left side)
LCD latch
Rear panel
Battery
Power switch
Power supply cord
AC adapter
