2.1 Installation

2.1.3 Three-Port Probe Unit

There are three transducer connectors, which are selectable through the operation of the mini console of the system

or the touch panel without removing the transducer.

Three-Port Probe Unit

IMPORTANT

•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

• Three-Port Probe Unit is intended to receive its power from the main unit through the transducer connector on the

main unit.

•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

HINT

• With a Three-Port Probe Unit connected to the system, the cable for the connector of the transducer connected to

the system is oriented toward the back.

Reference

• For details on how to connect a transducer when the system is equipped with a Three-Port Probe Unit, refer to

"Three-Port Probe Unit" of the"Operation Manual: Applications".

• For details on how to switch a transducer, refer to "4.2.1 Changing Exam Type Using the Shortcut Window".
