Konica Minolta SONIMAGE HS2 - 1.4 Specifications

47
Chapter 1
Item Description
Operation environment
Ambient temperature :10 °C to 35 °C
Relative humidity :30 % to 80 % (no condensation)
Atmospheric pressure :700 hPa to 1060 hPa
Altitude :3000 m or less
Storage and transportation envi-
ronment
Ambient temperature:
-20 °C to 60 °C (30 days)
-20 °C to 40 °C (90 days)
-20 °C to 20 °C (1 year)
(The following applies when the main unit is equipped with the Clear Ball (option).):
-10 °C to 45 °C (30 days)
-10 °C to 40 °C (90 days)
-10 °C to 20 °C (1 year)
Relative humidity :20 % to 80 % (no condensation)
Atmospheric pressure :700 hPa to 1060 hPa
Power Input
Main Unit
Line voltage :DC 24 V
Power consumption :7.5 A
AC Adapter
Line voltage :AC 100 V to 240 V
Line frequency :50 Hz / 60 Hz
Power consumption :2.5 A
Power Extension Unit2
Line voltage :AC 100 V to 240 V
Line frequency :50 Hz / 60 Hz
Power consumption :4.05 A to 1.81 A
Power Output
Main Unit
Power-supply voltage :DC 12 V
Current capacity :0.6 A
Mass
Main Unit :7.9 kg (including Battery)
System :45 kg or less (including Pole Cart2)
Size
369 mm (W) × 90 mm (H) × 452 mm (D)
(A height of 366 mm in a state where the LCD monitor is opened in an upright position, with its
projections excepted)
Display (LCD monitor)
Size :15 inch (38 cm)
Resolution :1024 (W) × 768 (H)
Reference
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••
• For measurement accuracy, refer to "11.3 Accuracy of Measurement".
• For transducer specications, refer to "8.1.2 Specications of Transducer".
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••
