1.6 System Conguration and Part Name
1.6.7 Connectable Transducers and Biopsy Brackets
A transducer is a device designed for transmitting / receiving ultrasound.
The system supports the following transducers and biopsy brackets, which are all optional.
The transducer that can be used with the system varies depending on the unit.
z
Transducer
Name Main indications for use
LINEAR PROBE L18-4 Peripheral vascular, Supercial, Musculoskeletal
CONVEX PROBE C5-2 Abdomen
SECTOR PROBE S4-2 Cardiac, Abdomen
LINEAR PROBE L14-4 Peripheral vascular, Supercial, Musculoskeletal
ENDOCAVITY PROBE EC9-3 Transvaginal
LINEAR PROBE L11-3 Peripheral vascular, Supercial, Musculoskeletal
LINEAR PROBE HL18-4 Peripheral vascular, Supercial, Musculoskeletal
CONVEX PROBE MC10-3 Peripheral vascular, Abdomen, Musculoskeletal
LINEAR PROBE WL13-3 Breast, Supercial, Musculoskeletal
SECTOR PROBE S4-2A Cardiac, Abdomen
z
Biopsy bracket
Available Transducer Biopsy bracket Additional needle guide/transducer cover
LINEAR PROBE L18-4
Biopsy Starter Kit (L18-4)
(Product No.: 693-004)
Ultra-Pro II
TM
Needle Guide Set
(Product No.: 610-608)
CONVEX PROBE C5-2
Biopsy Starter Kit (C5-2)
(Product No.: 693-003)
Ultra-Pro II
TM
Needle Guide Set
(Product No.: 610-608)
LINEAR PROBE L14-4
Biopsy Starter Kit (L14-4)
(Product No.: 693-005)
Ultra-Pro II
TM
Needle Guide Set
(Product No.: 610-608)
LINEAR PROBE L11-3
Biopsy Starter Kit (L11-3)
(Product No.: 693-006)
Ultra-Pro II
TM
Needle Guide Set
(Product No.: 610-608)
CONVEX PROBE MC10-3 -
Latex-Free Ultrasound Probe Covers
CIV-Flex
TM
Covers
(Product No.: 610-542)
LINEAR PROBE WL13-3 -
Latex-Free Ultrasound Probe Covers
CIV-Flex
TM
Covers
(Product No.: 610-542)
Reference
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••
• For information on how to connect a transducer, refer to "2.1.2 Connecting the Transducer".
• For other details, refer to "Chapter 8 Transducer and Biopsy".
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••
