Chapter 1

1.6 System Conguration and Part Name

1.6.6 Compatible Peripheral Devices

The following external devices can be used by connecting to the system.

• Connect them to the system using the corresponding ports as necessary.

Where to connect Connection device name

System SD memory card slot SD memory card

DVI-D port

External monitor

Products complying with IEC60950-1 or equivalent safety standards

USB port

Wireless LAN adapter

Items complying with IEEE 802.11n, IEEE 802.11a, IEEE 802.11g or IEEE 802.11b.

The compatible standard di󰀨ers depending on the wireless LAN adapter.

Only the items authorized by Konica Minolta.

To use the wireless LAN connection, an optional "Wireless LAN License" is required.

For how to use the adapter, refer to the instruction manual of the wireless LAN

adapter.

USB microphone

Only the items authorized by Konica Minolta.

For how to use the USB microphone, refer to the instruction manual of the USB

microphone.

Connect the USB microphone to the USB2.0 port on the rear panel.

IMPORTANT

•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

• If any external device connection is detected, an icon will be shown in the status indicator area on the monitor. An

icon for the network connection status is also shown in the status indicator area.

Refer to "Status indicator icon" of "1.6.5 Monitor".

• For details on how to operate peripheral devices, refer to their respective operation manuals.

•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

HINT

• Connect an SD memory card to the slot on the left side of the side panel.

• It may not be possible to use wireless LAN depending on the country and area.
