With the system you can use three types of diagnosis modes: basic scanning, mixed and multi-image.
Select the desired button from the mode button area to change the diagnosis mode.
Mode button area
The currently selected scanning mode is lit, showing
that it is in active use.
• Basic scanning mode:
B-mode is applied with a di󰀨erent mode(s).
• Mixed mode:
Two or three di󰀨erent basic scanning modes are applied to an image simultaneously. The images can be
viewed on a single screen.
• Multi-image mode:
The images can be viewed on a two-part split screen. Since each subscreen can display a di󰀨erent image, this
function is very useful for displaying the image of a body part or internal organ on multiple screens simultane-
ously. In addition, a B image can be seen in combination with the trace data pointed by the cursor on the B
image.
