164
Dual mode and Split mode are supported. Two images are arranged side by side or one above the other so that you
can compare the two images simultaneously.
In addition, it also supports trace mode that enables the simultaneous display of M-, PW / CW Doppler-, or PW-TDI-
mode’s trace data, so you can display a B image and trace data simultaneously.
Dual mode allows images to be displayed in each mixed mode. An active screen, called an "active plane," is indicat-
ed by its top scale with a blue horizontal line marked on it. The buttons on an active plane are operated in the same
manner as in a mixed mode.
4.6.1 Dual Mode
Dual mode is a mode that splits the screen into two windows positioned side by side (L/R) or one above the other (U/
D) for display.
One of the two images is in a live state, and the other is in a frozen state. They are displayed as a B image or a Bc
image.
1
Press or in the mode button area.
• Split screen is displayed.
z
To switch between active planes
1
Press .
• Switches between active planes each time you press the button.
• Touching the non-active screen also allows you to switch between active planes. Refer to the item "Active
Plane Indicator on Dual Mode" under "Image Screen" in the "Operation Manual: Applications".
z
To return to a single screen
1
Press .
HINT
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••
• The buttons to be displayed in the mode button area are customizable. If you want to use a dedicated button to
switch between live / frozen states in dual mode, make settings to have the following buttons displayed on the [Mode
Button] screen.
[Dual L] button
[Dual R] button
Refer to "[Mode Button] customize" in "Menu Customize Screen" of the "Operation Manual: Applications".
• Press to change the layout of dual mode. Also, the [Dual], [Dual L], and [Dual R] buttons will switch according
to the layout.
• In Elastography-mode, Dual-mode is available only when switched to Single-mode by pressing the [Display Mode]
menu button.
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••
4.6 Multi-image Mode
