Konica Minolta SONIMAGE HS2 - 11.6 Electromagnetic Emissions and Immunity

302
This product complies with the EMC standard IEC 60601-1-2 : 2014.
z
Compliance level of Electromagnetic Emission and Electromagnetic Immunity (applied to IEC
60601-1-2:2014)
Refer to "Important Information" for information of intended use.
Electromagnetic Emissions
Phenomenon EMC standard Emission compliance level
Conducted and radiated
RF EMISSIONS
CISPR 11 Group 1 Class B
Harmonic distortion IEC 61000-3-2 Class A
*
Voltage uctuations
and icker
IEC 61000-3-3 Complies
*
*
: These test items are not applied to the product with nominal voltage less than AC 220 V.
Electromagnetic Immunity
Phenomenon EMC standard Immunity compliance level
Electorostatic Discharge IEC 61000-4-2
±8 kV condact
±2 kV, ±4 kV, ±8 kV, ±15 kV air
Radiated RF EM elds IEC 61000-4-3 10 V/m, 80 MHz~2.7 GHz, 80 % AM at 1 kHz
Proximity elds from RF
wireless communications
equipment
IEC 61000-4-3
27 V/m, 385 MHz, Pluse modulation 18 Hz
28 V/m, 450 MHz, FM±5 kHz deviation 1 kHz sine
9 V/m, 710, 745, 780 MHz, Pulse modulation 217 Hz
28 V/m, 810, 870, 930 MHz, Pulse modulation 18 Hz
28 V/m, 1720, 1845, 1970 MHz, Pulse modulation 217 Hz
28 V/m, 2450 MHz, Pulse modulation 217 Hz
9 V/m, 5240, 5500, 5785 MHz, Pulse modulation 217 Hz
Electrical fast transients /
bursts
IEC 61000-4-4
±2 kV for power supply lines, 100 kHz repetition frequency
±1 kV for input/output lines, 100 kHz repetition frequency
Surges IEC 61000-4-5
±0.5 kV, ±1 kV Line-to-line
±0.5 kV, ±1 kV, ±2 kV Line-to-ground
Conducted disturbances
induced by RF elds
IEC 61000-4-6
3 Vrms,
0.15 MHz~80 MHz,
6 V in ISM and amateur radio bands between 0.15 MHz and
80 MHz a), 80 % AM at 1 kHz
Rated power frequency
magnetic elds
IEC 61000-4-8 30 A/m, 50 Hz or 60 Hz
Voltage dips IEC 61000-4-11
0 % U
T
; 0.5 cycle,
At 0°, 45°, 90°, 135°, 180°, 225°, 270° and 315°
0 % U
T
; 1 cycle
and
70 % U
T
; 25/30 cycle b),
Single phase: at 0°
Voltage interruptions IEC 61000-4-11 0 % U
T
; 250/300 cycle b)
NOTE: U
T
is the a.c. mains voltage prior to application of the test level.
a): The ISM (industrial, scientic and medical) bands are 6.765 MHz to 6.795 MHz; 13.553 MHz to 13.567 MHz;
26.957 MHz to 27.283 MHz; and 40.66 MHz to 40.70 MHz.
Amateur radio bands are 1.8 MHz to 2.0 MHz; 3.5 MHz to 4.0 MHz; 5.3 MHz to 5.4 MHz; 7.0 MHz to 7.3 MHz;
10.1 MHz to 10.15 MHz; 14.0 MHz to 14.2 MHz; 18.07 MHz to 18.17 MHz; 21.0 MHz to 21.4 MHz; 24.89 MHz to 24.99 MHz;
28.0 MHz to 29.7 MHz; and 50.0 MHz to 54.0 MHz.
b): E.g. 10/12 means 10 periods at 50 Hz or 12 periods at 60 Hz.
11.6 Electromagnetic Emissions and Electromagnetic Immunity
