Chapter 2
2.1 Installation
3
Raise the lock lever to secure the transducer.
Transducer connector lock
4
Turn ON the system.
• The attached transducer is recognized by the system so that the frequency display and icon will be changed
accordingly.
z
How to remove
1
Turn OFF the system.
2
Lower the transducer connector lock lever to unlock.
3
Hold the transducer by its connector and pull it laterally out of the transducer connec-
tor.
