4.4 Basic Scanning Mode
138
Item Functions
[THI] THI settings for B- and M-mode
[Param. Disp.]
Sets whether to display parameters during dual mode (displaying images side-by-side).
• When it is set to [O󰀨] or [Trans.], the ultrasound image is also displayed even in the parameter
display area.
• When it is set to [Trans.], both the ultrasound image and parameters are displayed.
[TD Guide]
Sets Show / Hide of the scale marked on the transducer on the screen.
• Enabled when the biopsy guide display is set to OFF.
• This is enabled when a linear transducer or MC10-3 transducer is equipped.
[Auxiliary Line]
Sets and displays an auxiliary line(s) in the depth direction.
• The interval between auxiliary lines varies depending on the display depth.
• Enabled when the biopsy guide display is set to OFF.
[Aux. Line Type] Sets the display range for the auxiliary line.
[Sound Speed] • Sets the velocity used for incoming data.
[B Filter] Sets the internal parameters of B images.
[UD Flip]
Reverses the image in the vertical direction.
• M-mode is also simultaneously operated.
[B iXRET] Sets a process to improve resolution for B-mode.
HINT
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••
• [Dual Layout] can be assigned to the mode button area. In that case, you can select [L/R] or [U/D 1] only.
Refer to "[Mode Button] customize" in "Menu Customize Screen" of the "Operation Manual: Applications".
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••
