4.4 Basic Scanning Mode
151
Chapter 4
SCF-mode parameter list
Item Functions
[Tx Level]
Sets the transmission voltage.
• Displayed in all modes.
[C Scale] Flow velocity setting for SCF-mode
[C Steer]
Steer angle setting for SCF-mode
• Enabled when a linear transducer has been connected to the system.
[C Gain] Gain setting for SCF-mode
[C Filter] MTI lter setting for SCF-mode
[C Frequency]
Frequency setting for SCF-mode
• The actual frequency value di󰀨ers for each transducer.
[Temporal] Repeated transmission count setting for SCF-mode
[C Density]
Acoustic line density setting for SCF-mode
• [L] can be selected if a linear transducer is connected.
[Motion Sup.] Motion artifact reduction setting for SCF-mode
[Spatial Avg.] Spatial direction smoothing setting for SCF-mode
[C Time Avg.] Time direction smoothing setting for SCF-mode
[C Priority]
Display priority setting for SCF-mode
• A larger value represents a higher priority, being more e󰀨ective in overriding B-mode.
[C Invert] Color invert setting for Directional SCF-mode
[C Baseline] Baseline setting for SCF-mode
[Color Map]
Map setting for SCF-mode
• Map for Directional SCF-mode is included.
[P DR] Dynamic range setting for SCF-mode
[Power Cut O󰀨] Reduced power cut setting for SCF-mode
[FR priority]
Setting for changing the B mode parameter to increase the SCF-mode frame rate.
• When [FR Priority] is set to anything other than [O󰀨], the setting values of THI and acoustic line
density may be limited.
[C SI-Filter] Image processing setting for SCF-mode
[C iXRET]
Sets a process to improve resolution for CFM/PDI/SCF mode.
• The parameter range depends on the transducer used.
[Simple Adjust]
The following adjustments are done in the relevant modes.
• Auto C ROI adjustment in SCF-mode
• Auto Doppler gate adjustment in PW Doppler-mode
• Auto ow velocity adjustment in PW Doppler-mode/CW Doppler-mode/PW-TDI-mode
