4.4 Basic Scanning Mode
159
Chapter 4
PW-TDI-mode parameter list
Item Functions
[Tx Level]
Sets the transmission voltage.
• Displayed in all modes.
[Gate Size] Sample volume size setting
[Angle Correct.] Angle correction setting
[D Scale] Flow velocity setting
[D Baseline] Baseline setting
[D Gain] Gain setting
[Sweep Speed] Sweep speed setting
[Angle] Sets angle to 60°, 0°, or -60°
[D Layout] Display layout setting
[D Filter] Wall lter setting
[D Invert] Display invert setting
[D Color] Color setting
[D Map] Brightness curve setting
[D DR] Dynamic range setting
[Audio Volume] Audio volume setting
[Audio Balance] Audio balance setting
[Trace Thresh.] Trace threshold setting
[Trace Smooth] Trace smoothing setting
[Trace Mean] Trace Mean setting
[Trace Max] Trace Max setting
[Simple Adjust] Auto ow velocity adjustment in PW-TDI-mode
[Reject] Removal of noise in luminance direction
