4.4 Basic Scanning Mode

161

Chapter 4

CW Doppler-mode parameter list

Item Functions

[Tx Level]

Sets the transmission voltage.

• Displayed in all modes.

[Angle Correct.] Angle correction setting for CW Doppler-mode

[D Scale] Flow velocity setting for CW Doppler-mode

[D Baseline] Baseline setting for CW Doppler-mode

[D Gain] Gain setting for CW Doppler-mode

[Sweep Speed] Sweep speed setting for CW Doppler-mode

[Angle] Sets angle to 60°, 0°, or -60°

[D Layout] Display layout setting for CW Doppler-mode

[D Filter] Wall lter setting for CW Doppler-mode

[D Invert] Display invert setting for CW Doppler-mode

[D Color] Color setting for CW Doppler-mode

[D Map] Brightness curve setting for CW Doppler-mode

[D DR] Dynamic range setting for CW Doppler-mode

[Audio Volume] Audio volume setting for CW Doppler-mode

[Audio Balance]

Audio balance setting for CW Doppler-mode

• L, C, and R mean left, center, and right, respectively.

[Trace Thresh.] Trace threshold setting for CW Doppler-mode

[Trace Smooth] Trace smoothing setting for CW Doppler-mode

[Trace Mean] Trace Mean setting for CW Doppler-mode

[Trace Max] Trace Max setting for CW Doppler-mode

[Simple Adjust] Auto ow velocity adjustment in CW Doppler-mode

[Reject] Noise removal setting for CW Doppler-mode
