4.8 Panoramic View
180
List of parameters for B-Mode when starting up panoramic view
The list of parameters for B-mode when starting up panoramic view are as follows.
Item Functions
[Tx Level] TX level settings
[Focus Position]
Focal position setting for B-mode
• The actual focal position depends on the transducer used.
[B Frequency]
Frequency setting for B-mode
• For the parameter range, sequentially select all the frequencies that are available for the trans-
ducer.
[B Gain] Gain setting for B-mode
[Depth]
B image depth settings
• The maximum depth depends on the transducer used (or the exam type).
• Minimum depth values di󰀨er for each transducer.
[B DR] Dynamic range setting for B-mode
[B Map] Map brightness curve setting for B-mode
[P Time Avg.] Persistence setting for B-mode
[Edge Enhance] Edge enhance setting for B-mode
[Simple Adjust] Auto gain adjustment
[S.Adjust Quit] Turns o󰀨 automatic adjustment of image quality.
[B Color] Color setting for B-mode
[Sound Speed] Sets the velocity used for incoming data.
[B SI-Filter] Speckle noise reduction setting for B images
[THI] THI settings for B-mode
[TD Guide] Sets Show / Hide of the scale marked on the transducer on the screen.
IMPORTANT
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••
• The following settings change automatically when you enter Panoramic View.
– [B Density]: [H]
– [Compound]: [1]
– [Trapezoid]: [O󰀨]
– [Focus Pattern]: 1
– [Biopsy], [SNV]: [O󰀨]
– [ECG]: [O󰀨]
• When using Panoramic View, M-mode/PW Doppler-mode/PW-TDI/Color ow/Power Doppler/SCF-mode/ Elastogra-
phy-mode cannot be activated.
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••
