Konica Minolta SONIMAGE HS2 - Measurement Items for Various Modes

5.4 Measurement
197
Chapter 5
Measurement item Functions
FPC (Flow
Pixel Coun-
ter)
*
1
[FPC 15x5mm]
[FPC 15x10mm]
[FPC 30x20mm]
[FPC Rect]
[FPC Free]
[FPC ROI]
Calculates the ratio of the area of a specic area (FPC Box) to the
area of blood-ow signals present within the specic area.
Auto IMT
*
2
[Auto IMT-Near]
Automatically calculates IMT (Intima Media Thickness).
[Auto IMT-Far]
[Manual IMT]
IMT (Intima Media Thickness) measurement that manually mea-
sures thickness at three to ve points.
[Histogram Fix]
Analyzes the gray levels within the square measurement area of
xed size to display a histogram.
[Histogram Free]
Analyzes the gray levels within the rectangular measurement area
of variable size to display a histogram.
[Strain Ratio]
*
3
Calculates the ratio of the average amount of strain in two mea-
surement areas.
[Strain Histogram]
*
3
Analyzes the elasticity in the measurement area and displays a his-
togram.
[E/B Ratio]
*
3
Measures the ratio of Length (E) of two random points in the elas-
tography screen and Length (B) of two random points in screen B.
*
1: Measurements of each FPC item can be obtained only when an image is frozen in Power Doppler- / SCF-mode.
*
2: Use of Auto IMT requires the optional "Auto IMT License".
*
3: You will require the optional "Strain Elastography License" to use the item. Measurement is only enabled when the image is
frozen in Elastography-mode.
z
List of Measurement Items for M-mode
For details, refer to "M-mode Measurement" of the "Operation Manual: Applications".
Measurement item Functions
[Distance] Calculates the distance in the depth direction between two points.
[Time] Calculates the time between two points.
[HR]
Calculates the number of heartbeats per minute based on the heart rate
displayed on the screen.
[Slope] Calculates the tilt between two points.
[Velocity] Calculates the velocity between two points.
[A/B Ratio]
[Time Ratio] Calculates the ratio of time between two lines.
[Dist Ratio] Calculates ratio of two distances.
z
List of Measurement Items for Color Flow-mode
Measurement items for Color Flow-mode are the same as the ones for B-mode.
z
List of Measurement Items for Power Doppler-mode
Measurement items for Power Doppler-mode are the same as the ones for B-mode.
z
List of Measurement Items for 2D-TDI-mode
Measurement items for 2D-TDI-mode are the same as the ones for B-mode.
